Tyre Shredding Machine

Tire shredders are specialized machines in the recycling industry, designed to diminish the volume of tires by employing high-torque shredding mechanisms. Available in various models, they are capable of processing substantial volumes of tires of diverse sizes. By cutting, slicing, and crushing end-of-life tires (ELTs), these shredders transform them into rubber chips. Tire shredding serves as an essential technique for recycling, reprocessing, and transforming waste tires into valuable products.

Tire Recycling Line Technical Parameter:

Model	YG-3	YG-6	YG-10	YG-16	YGL-16	YG-30
Capacity	1-3t/d	4-6t/d	8-10t/d	12-16t/d	8t/d (only for rubber powder)	30-35t/d
Working Process	Batch	Batch	Batch	Batch	Semi-continuous	Fully continuous
Reactor Size	φ1400*4900mm	φ2200*6000mm	φ2600*6600mm	φ2800*7100mm	φ2800*7100mm	φ1800*18500mm
*Land (LWH)*	18m4.2m6m	30m12m8m	30m13m8m	33m13m8m	33m13m8m	70m20m10m
Power	16.65kw	37.85kw	44.3kw	55.6kw	55.6kw	256kw
Burner	2*200,000 kcal	2*300,000 kcal	2*300,000 kcal	2*400,000 kcal	2*400,000 kcal	2.5 million kcal per set
Total Weight of Shipped Materials	About 18t	About 24.5t	About 28t	About 34.5t	About 34.5t	About 150t
Noise (dB)	≤60	≤60	≤60	≤60	≤60	≤60

6 Features of Tyre Shredding Machine:

Heavy moving blade, high crushing efficiency, the blades are cast with alloy steel, strong and long service life.

The thick frame plate can resist high torque and is very strong.

It adopts microcomputer (PLC) automatic control, with start, stop, reverse, and overload automatic reverse control functions.

The equipment has the characteristics of low speed, high torque, low noise, and dust that can meet environmental protection standards.

Easy to adjust, low maintenance cost, economical, and durable.

The thickness of the blade and the number of claws can be replaced according to different materials.

Application Fields of Shredded Tires:

Sports ground patching:

Running tracks, school sports grounds, swimming pools around and garden paths, bowling greens, sidewalks, kindergarten sports grounds and playgrounds, tennis and basketball courts.

Automotive industry:

Floor mats for trains, flooring for cars and trucks, marine daily materials, tires, and tire pads.

Construction equipment:

Adhesives/sealants, hospitals, companies, bathroom floors, insulation materials, coatings, dams, warehouses, ponds, waste treatment stations, house signs, sheets, waterproofing materials, shockproofing, coils, waterproofing materials for roofs and walls.

Production of recycled rubber amines:

Used in the production of various rubber systems.

System Features

Capacity	200-2000 kg/h
Scope of Application	The diameter of the tire from 400 to 3000mm, including car tire, passage tire, bus tire, truck tire and OTR tire.
Output Size	5-100 mesh. Crumbs or powder is customizable.
Characteristic	● Complete separation: Crumbs, steel and fiber can be separated automatically. ● Control system: Adopt a PLC control system, which is simple and easy to control and maintain5 people to operate a Tire recycling (beads) production line with 3000kg/h capacity. ● The installed power of the Tire recycling production (beads) line with capacity. 3,000kg/h is about 550kw.
Power consumption	500+ kW
Equipment required area	About 400 square meters, 6 meter high max

Different Types of Tire Shredders

Since the rubber blend of a tire needs to go through a number of refinement processes before it can be used, each tire shredder machine varies in its internal mechanical design and process. Consider the following common types of tire shredding equipment:

Shear Shredders:

Shear shredders are typically low-speed and employ two-shaft rotary knives to cut materials.

Chippers:

Chippers can be single or multiple-stage contraptions that use high-speed rotary knives, wheels and drums in the process to cut materials into chips.

Grinders:

Grinders work on either high or low speed using wheels, drums, and plates in the abrasion process, often combined with compression to crush materials.

Granulators:

Granulators vary widely in size and mechanics and employ units that use knives to cut parts into fine particles.

Speciality Shredders:

Speciality shredders in the case of tires are designed to forcefully tear the tire into small pieces using rotary shafts at low speeds, under very high torque.
