The automatic concrete leveling machine is an intelligent, high-precision flooring construction device and a mainstream concrete floor leveling machine in the engineering field. Specifically developed to replace traditional manual concrete leveling processes, it is widely used in the standardized construction of various large-area floors. The equipment integrates laser positioning, intelligent electronic control, and a hydraulic leveling system, completely solving the pain points of manual leveling such as large errors, low efficiency, and poor finish.
The equipment supports fully automatic, uniform-speed operation, eliminating the need for repeated manual leveling and calibration. It can be operated independently by a single person, achieving a construction efficiency 8-10 times that of traditional manual methods. It can quickly complete flooring construction for various types of buildings, including factories, warehouses, parking lots, supermarkets, and basements. It is adaptable to different concrete slumps and pouring thicknesses ranging from 5- 30 cm, suitable for both large and small area projects, making it highly versatile.
As a cost-effective intelligent construction device, the automatic concrete leveling machine is easy to operate, has a low failure rate, and has low daily maintenance costs. The manufacturer provides a complete warranty, a full range of spare parts, and comprehensive construction technical guidance, making it the core preferred equipment for small and medium-sized construction teams to reduce labor costs, shorten construction periods, and improve floor acceptance rates. If you are also interested, please contact us now for more product information.
Hot-sale YG Concrete Laser Leveling Screed Machine Technical Parameter
|
Model |
YGJX31 |
YGJX32 |
YGJX33 |
YGJX34 |
|
Engine |
||||
|
Model |
Generator set |
GX390 Electric start |
GX390 Electric start |
GX390 Electric start |
|
Power |
2.0kW |
13hp/3600rpm |
13hp/3600rpm |
13hp/3600rpm |
|
Fuel tank (L) |
14.5 |
6.5 |
6.5 |
6.5 |
|
Running device |
||||
|
Drive |
Motor |
Hydraulic motor |
Hydraulic motor |
Hydraulic motor |
|
Running mode |
Infinitely variable speed |
Handle control, stepless speed |
Handle control, stepless speed |
Handle control, stepless speed |
|
Running speed(m/min) |
0-36 |
0-45 |
0-65 |
0-45 |
|
Suggest working speed(m/min) |
5 |
5 |
5 |
5 |
|
Screed head |
||||
|
Type |
Self-leveling |
Electric control, self-levelling |
Self-leveling |
Hydraulic control, self-levelling |
|
Width |
2500mm |
2500mm |
2500mm |
2500mm |
|
Exciting force |
500N |
500N |
500N |
500N |
|
Vibration frequency |
50Hz |
50Hz |
50Hz |
50Hz |
|
Laser control system |
||||
|
Control type |
Microcomputer laser scan |
Microcomputer laser scan |
Microcomputer laser scan |
Microcomputer control |
|
Operation mode |
Walk-behind |
Walk-behind |
Walk-behind |
Walk-behind |
|
Forward and reverse |
Handgrip control, stepless speed-walking |
Hydraulic control |
Handgrip control, stepless speed-walking |
Hydraulic control |
|
Size and weight |
||||
|
Working size(mm) |
2758*2622*1980 |
2740×2659×1980 |
2578×2643×1980 |
2780*2622*1980 |
|
Weight(kg) |
295 |
365 |
380 |
410 |
8 Core Application Areas of YG Automatic Concrete Leveling Machine
Industrial Plant Flooring
Heavy-duty flooring construction for large production workshops and warehouses.
Logistics Warehousing Flooring
Ultra-flat flooring for e-commerce warehouses and logistics parks, suitable for forklift and AGV operation.
Parking Lot Flooring
Large-area leveling for underground garages and open-air parking lots.
Shopping Mall/Supermarket Flooring
Smooth and wear-resistant flooring for large shopping malls and supermarkets.
Airport Runway Flooring
High-precision leveling construction for airport runways and aprons.
Municipal Road Flooring
Concrete leveling for plazas, sidewalks, and non-motorized vehicle lanes.
Sports Stadium Flooring
Basement flooring construction for basketball courts, tennis courts, and sports fields.
Residential Basement Flooring
Leveling work for residential basements and underground garages.
Demonstration of YG's Fully Automated Laser Leveling Machine Use by Malaysian and German Clients
Case Study 1: Industrial Plant Flooring Project in Malaysia
- Client Background: A construction company in Kuala Lumpur, Malaysia, undertook a 15,000㎡ electronics factory flooring project, requiring a flatness of ±3mm and a 15-day timeframe.
- Problems Faced: Manual leveling was inefficient, failing to meet flatness requirements, resulting in multiple reworks in previous projects.
- Solution: Purchased two standard automatic concrete leveling machines, along with specialized edge leveling tools.
- Results: Daily construction area reached 2200㎡, all leveling work was completed in 7 days, flatness tests all met standards, and acceptance was passed on the first attempt. Labor was reduced from 12 people to 2, saving 60% in costs.
- Customer Testimonial: "This equipment is amazing! The flatness and efficiency far surpass manual labor. We'll use your machines for all our future flooring projects."
Case Study 2: German Logistics Warehouse Flooring Project
- Client Background: A logistics company in Hamburg, Germany, was building a new 30,000㎡ automated warehouse, requiring an ultra-flat floor suitable for AGV (Automated Guided Vehicle) forklifts.
- Solution: Purchased three high-spec, large-scale automatic concrete leveling machines with a 360° laser positioning system.
- Results: Floor flatness reached ±2mm/3m, fully meeting AGV operation requirements. Zero rework during construction, completed 10 days ahead of schedule, receiving high praise from the client.
- Customer Testimonial: "The equipment is highly precise and runs stably. Local German equipment costs three times as much as yours, making it incredibly cost-effective."
Act Now and Get Your Customized Flooring Construction Plan!
Automatic concrete leveling machines, with their core advantages of high precision, high efficiency, and low cost, have become standard equipment in modern flooring construction. They perfectly solve the pain points of manual leveling, such as poor flatness, low efficiency, and high cost. Combined with the full range of concrete floor leveling machines, they can meet the construction needs of floors of all sizes.
Now, just tell us: What is the size of your construction area? What is the required flatness level? What type of flooring do you want?
We will provide you with:
- Customized machine model and configuration plan.
- Precise quotation and parts list.
- On-site construction operation video and maintenance manual.
- Free training and technical support.
Contact us now, and we can provide you with a plan within 24 hours, helping you quickly start your project, save costs, and successfully pass acceptance!
