YG flat pack container house is a house product that is packed and transported in a flat form after the main structural components of the container house (such as top frame, bottom frame, wall panels, columns, etc.) are prefabricated in the factory. After arriving at the site, it can be quickly assembled into a complete, habitable, or usable space unit through simple bolt connections. It is widely used in various places that require fast construction and flexible use. Contact us for more product information.
Flat Pack Container House Parameter:
|
20FT Basic Characteristics
|
External dimension (mm) |
W6320*L5900*H2480(Side 2270) |
|
Internal dimension (mm) |
W6160*L5560*H2240(Side 2150) |
|
|
Folded state (mm) |
W2200*L5900*H2480 |
|
|
Total mass (kg) |
2500 |
|
|
30FT Basic Characteristics
|
External dimension (mm) |
W6360*L9000*H2480(Side 2180) |
|
Internal dimension (mm) |
W6200*L8660*H2240(Side 2060) |
|
|
Folded state (mm) |
W2200*L9000*H2480 |
|
|
Total mass (kg) |
3750 |
|
|
40FT Basic Characteristics
|
External dimension (mm) |
W6240*L11800*H2480(Side2180) |
|
Internal dimension (mm) |
W6080*L11540*H2200(Side2060) |
|
|
Folded state (mm) |
W2200*L11800*H2480 |
|
|
Total mass (kg) |
4400 |
|
|
Smaller Fold Size
|
External dimension (mm) |
W4820*L5900*H2480(Side2270) |
|
Internal dimension (mm) |
W4660*L5560*H2240(Side2150) |
|
|
Folded state (mm) |
W700*L5900*H2480 |
|
|
Total mass (kg) |
1850 |
Why do More and More Customers Choose Flat-pack Container Houses?
The core advantage of YG flat pack container house lies in its flat packaging and quick assembly design. In the factory, the various components of the house (top frame, bottom frame, corner column, wall panel, roof panel, etc.) are precisely manufactured and surface-treated. Then, these components are carefully packed into flat packages to save transportation space to the maximum extent. When the goods arrive at the construction site, it is only necessary to assemble the various components using bolts and other connectors according to the provided installation drawings and instructions. The whole process is similar to assembling large building blocks, without a lot of on-site welding or cutting work, which greatly simplifies the construction process and shortens the installation time.
Choosing YG Flat Pack Container House Will Bring Practical Benefits to Your Project:
- Reduced transportation costs: Flat packaging saves a lot of transportation space, especially for projects that require long-distance transportation, the cost advantage is very obvious.
- Speed up construction: On-site assembly is simple and fast, which greatly shortens the construction period and can be put into use quickly.
- Strong flexibility: The modular design can be combined and expanded according to different needs to meet various space requirements, whether it is temporary or semi-permanent construction.
- Sturdy and safe: The use of high-quality materials and structural design ensures the sturdiness and safety of the house and can withstand bad weather.
- High-cost performance: Compared with traditional construction methods, a flat pack container house has advantages in cost control, especially considering its quick installation and reusability. You can learn about our prefab container house price, I believe it will bring you surprises.
