YG hydraulic cone crusher is efficient crushing equipment that integrates high swing frequency, optimized cavity shape, and laminated crushing principle. It adopts advanced hydraulic technology and intelligent control system, and can efficiently crush ores and rocks of various hardness, especially good at processing high-hardness materials such as granite, basalt, and river pebbles. This machine has high production efficiency, good finished product particle shape, stable and reliable operation, and easy maintenance. It is ideal for large-scale mines, sand and gravel aggregate fields, construction waste treatment, and other industries. If you are looking for a high-performance cone crusher, or want to know the hydraulic cone crusher price, please get in touch with us now.
Hydraulic Cone Crusher Parameter:
|
Model |
Cavities |
Feed opening (mm) |
Minimum discharging size (mm) |
Capacities (t/h) |
Maximum installed power (kW) |
Overall dimension (mm) |
|
YG100 |
C1(Extra Coarse) |
140 |
19 |
75-140 |
90 |
1705×1510×1583 |
|
C2(Coarse) |
100 |
13 |
60-110 |
|||
|
M(Medium) |
70 |
9 |
52-100 |
|||
|
F1(Fine) |
50 |
9 |
50-95 |
|||
|
F2(Extra Fine) |
20 |
6 |
45-90 |
|||
|
YG200 |
C2(Coarse) |
185 |
19 |
145-250 |
160 |
2135×1750×1927 |
|
M(Medium) |
125 |
16 |
135-235 |
|||
|
F1(Fine) |
95 |
13 |
115-220 |
|||
|
F2(Extra Fine) |
75 |
10 |
90-190 |
|||
|
YG300 |
C1(Extra Coarse) |
230 |
25 |
220-440 |
250 |
2725×2110×2871 |
|
C2(Coarse) |
210 |
19 |
190-380 |
|||
|
M(Medium) |
150 |
16 |
175-320 |
|||
|
F1(Fine) |
105 |
13 |
145-280 |
|||
|
F2(Extra Fine) |
80 |
10 |
110-240 |
|||
|
YG400 |
C1(Extra Coarse) |
295 |
30 |
300-630 |
315 |
2775×2370×2295 |
|
C2(Coarse) |
251 |
25 |
285-560 |
|||
|
M(Medium) |
196 |
20 |
250-490 |
|||
|
F1(Fine) |
110 |
13 |
180-345 |
|||
|
F2(Extra Fine) |
90 |
10 |
135-320 |
|||
|
YG500 |
C1(Extra Coarse) |
330 |
38 |
425-790 |
400 |
2800×3480×4050 |
|
C2(Coarse) |
290 |
30 |
370-700 |
|||
|
M(Medium) |
210 |
22 |
330-605 |
|||
|
F1(Fine) |
135 |
16 |
270-535 |
|||
|
F2(Extra Fine) |
95 |
13 |
220-430 |
|||
|
YG800 |
C1(Extra Coarse) |
350 |
38 |
570-1200 |
630 |
3970×3345×4235 |
|
C2(Coarse) |
299 |
32 |
520-1050 |
|||
|
M(Medium) |
265 |
25 |
475-950 |
|||
|
F1(Fine) |
220 |
16 |
370-800 |
|||
|
F2(Extra Fine) |
150 |
13 |
310-600 |
YG Hydraulic Cone Crusher Working Principle:
- Feeding: The material to be crushed enters the crushing chamber from the upper feed port of the crusher.
- Laminated crushing: Driven by the eccentric sleeve, the moving cone makes a swinging motion around the central axis, so that the material in the crushing chamber is squeezed, sheared, and ground between the moving cone and the fixed cone, realizing laminated crushing. The material is subjected to force at multiple points in the crushing chamber, and the particles are squeezed and crushed against each other, which reduces the over-crushing phenomenon and improves the crushing efficiency and the finished product particle shape.
- Discharging: The material crushed to a certain particle size is discharged from the discharge port at the bottom of the crusher under the action of gravity.
- Hydraulic protection: When the crusher is overloaded or enters an uncrushable object, the hydraulic system starts the protection function, adjusts the discharge port, or lifts the moving cone to prevent equipment damage.
- Cavity adjustment: By adjusting the hydraulic system, the crushing cavity type can be adjusted conveniently and quickly to adapt to different crushing requirements and material characteristics.
Hydraulic Cone Crusher Customer Cases and Feedback:
Case 1: A Small - Scale Mining Company in South Africa
A small-scale mining company in South Africa was struggling with inefficient crushing processes. They saw a significant improvement after purchasing a YG brand hydraulic cone crusher. The company's manager said, "This machine has completely transformed our operations. It's able to handle our ore volume with ease, and the quality of the crushed product has improved our downstream processing efficiency. The price we paid was very reasonable considering the benefits we've received."
Case 2: A Construction Aggregate Producer in the United States
A construction aggregate producer in the United States needed to upgrade their crushing equipment to meet the increasing demand for high-quality aggregates. They chose a YG-brand hydraulic cone crusher. The production manager commented, "The YG hydraulic cone crusher has been a great addition to our plant. It's easy to operate and maintain, and the ability to adjust the output size quickly has allowed us to meet different customer requirements. We're very satisfied with our purchase."
FAQ about YG Portable Stone Crusher:
Q: What types of materials can a hydraulic cone crusher crush?
A: Hydraulic cone crushers are versatile and strong, designed to crush a wide range of hard and abrasive materials. They excel at processing rocks like granite, basalt, quartzite, pebbles, and ores such as iron ore, copper ore, and gold ore.
Q: How is a hydraulic cone crusher transported and shipped?
A: Due to their large size and weight, hydraulic cone crushers are typically shipped by sea. YG Machinery, as the direct hydraulic cone crusher factory, takes care of all shipping arrangements. The crusher is carefully packaged and secured for safe transport. We handle loading, and documentation, and can arrange delivery to ports worldwide. We ensure a smooth and reliable shipping process for our customers globally.
Q: Is it difficult to operate and maintain a hydraulic cone crusher?
A: YG Machinery's hydraulic cone crushers feature intelligent control systems that simplify operation. Maintenance is also designed to be straightforward. We provide detailed manuals and videos. Routine checks and lubrication are key. As the manufacturer, YG Machinery offers full technical support and readily available spare parts to ensure easy maintenance and minimal downtime.
Q: What are the benefits of buying a hydraulic cone crusher directly from YG Machinery?
A: You get factory-direct prices, cutting out middlemen for better value. You have direct access to our engineering expertise for customization and support. We guarantee quality and provide comprehensive after-sales service and spare parts directly from the source. Choose YG Machinery for a reliable hydraulic cone crusher and a trustworthy partnership.
